Description
xContact us for a bulk quote
Number of channels: 3.3G band; A,B Frequency Groups.
16channels(A:3060MHz-3200MHz, B:3220MHz-
3360MHz)
Antenna Interface: Standard SMA
RF impedance: 50Ω
The input voltage: 2S-6S
Current consumption: 150mA/12VDC
Receiving Sensitivity:-95dBm
Video Output impedance:75Ω
Video format:NTSC/PAL
Video Output Level:CVBS 1.0~1.4VP-P
Power cable: DC3.5*1.35mm to DC5.5*2.1mm
Video cable: 4-pin 2.5mm headphone jack to RCA
adapter
Working Temp:-10-60°C
Mounting hole:M6
Dimension(L*W*H): 85mm*40mm*11mm
Weight: 36g
