Description
xContact us for a bulk quote
Number of channels: 4.9/6.2G band: ABEFRLX
Frequency Groups, (4990MHz-6180MHz)
Antenna Interface: Standard SMA
RF impedance: 50Ω
The input voltage:2S-6S
Current consumption: 150mA/12VDC
Receiving Sensitivity:-95dBm
Video Output impedance:75Ω
Video format:NTSC/PAL
Video Output Level:CVBS 1.0~1.4VP-P
Power cable: DC3.5*1.35mm to DC5.5*2.1mm
Video cable: 4-pin 2.5mm headphone jack to RCA
adapter
Working Temp:-10-60°C
Mounting hole: M6
Dimension(L*W*H): 77mm*50mm*11mm
Weight: 50g
